Overview
Flail Mowers
The MAJOR MJ24 Flail Mower is a robust machine designed for heavy grass cutting. The machine is offset by hydraulic control as standard.
This machine is suitable for pruning in the hardest of working conditions such as vineyards, orchards and green areas.
- 3 Point Linkage
- Hydraulic side shift
- Rear Roller and side skids
- Adjustable rear cover
- Rotor with hammers
The MAJOR MJ26 Flail Mower can be fitted to any tractor front or rear Cat II linkage,independently of the PTO direction.
This machine is suitable for the clearance of small trees, bush and heavy grass in amenity areas and on the verges of highways. It is also suitable for trimming grass and lighter growth as the blades can be easily changed.
- Double 3 Point Linkage (front/rear)
- Hydraulic side shift
- PTO shaft c/w overrun
- Gearbox with double PTO
- Rear roller and side skids
- CE certified; PTO guarding and safety flaps
Specifications
| Model | MJ24-230 | MJ24-280 | MJ26-230 | MJ26-280 |
| Working Width | 2.3m (7′ 6″) | 2.74m (8′ 11″) | 2.3m (7′ 6″) | 2.74m (8′ 11″) |
| Overall Width | 2.6m (8′ 6″) | 3m (9′ 10″) | 2.6m (8′ 6″) | 3m (9′ 10″) |
| Machine Height | 1.1m | 1.1m | 1.1m | 1.1m |
| Machine Depth | 1.2m | 1.2m | 1.2m | 1.2m |
| Hammers | 26 | 30 | 26 | 30 |
| No. Of Flails (Optional) | 52 | 60 | 52 | 60 |
| Power (HP) | from 80HP | from 100HP | from 80HP | from 80HP |
| PTO rpm | 540 | 540 | 540 – 1000 | 540 – 1000 |
| Belts | 4 | 5 | 4 | 5 |
| Weight | 794kg | 916kg | 900kg | 1026kg |
