Overview

Winged Roller Mowers (3 pt linkage)

The MAJOR winged 3 point linkage Swift roller mower is a high-output machines, suitable for the maintenance of parks, schools and sports grounds.  The high blade tip speeds of 90m/s give a perfect professional striped finish every time.

The wings fold neatly behind the tractor for safe transportation and allows entrance to sites where access is an issue.

Features:
  • 2.3m (MJ70-320) and 2.0m transport widths
  • Walterscheid PTO drive shafts fitted as standard
  • Wing lock for safe road transportation
  • Sits tight behind the tractor making towing easy and allows tighter turning circles
  • Two blade systems in one; a simple adjustment converts your blade from rigid blade to swinging blade
  • Optim™ high-strength steel is used to manufacture this mower. The overall weight of the machine is lighter than equivalent width mowers on the market, without compromising on build quality.
  • LED road lighting kit

Blades – Two blade systems in one; a simple adjustment converts your blade from rigid blade to swinging blade

Specifications

Model MJ70-320 MJ70-410 MJ70-550
Overall Width 3.3m (11′ 4″) 4.2m (13′ 9″) 5.6m (18′ 4″)
Working Width 3.2m (11′) 4.1m (13′ 5″) 5.5m (18′)
Transport Width 2.3m (7′ 6″) 2.0m (6′ 6″) 2.0m (6′ 6″)
Power (HP) 40-90 HP 50-100 HP 70-120 HP
PTO rpm 540 540 540
Cutting Height 10-150mm 10-150mm 10-150mm
Rotors 5 6 8
Blades 10 12 16
Weight 925kg 1130kg 1310kg
Blade tip speed 90 m/s 90 m/s 90 m/s
