Redrock Twin Auger Vertical Feeder

  • Overview
  • Specifications
  • Gallery

Overview

The Redrock vertical  Twin Auger Mixer Feeder can mix everything from big bales of silage, straw and hay, to precision cut grass silage, maize, meal and molasses etc.

Serrated Knives

Vertical Mixer - Serrated Knives

Serrated knives are used to efficiently chop fibrous foodstuffs to the length required for effective mixing and healthy digestion. The knives are designed to sharpen as they wear. Assisted by two counter knives which restrict material as it is driven past them.

Sweeper Arm

Vertical Mixer - Sweeper Arm

The auger incorporates a carefully positioned sweeper arm which has been painstakingly designed by Redrock to give a perfect blend of all your selected ingredients, time after time, and ensures and even, fluffy and appetising discharge that your livestock will find easy to eat.

Two Speed Drive Line Planetary System

Vertical Mixer - Two Speed Drive Line Planetary System

The two speed drive line planetary system is used to reduce horsepower requirements, lowering your fuel costs and free up larger tractors for other tasks on the farm.

Specifications

Model – Vertical Mixer Feeder – Twin Auger

Model 16VM SD 20VM SD 24VM SD 16VM RD 20VM RD
Capacity 16m3 20m3 24m3 16m3 20m3
Overall Height 2.91m 3.00m 3.15m 2.91m 3.00m
Overall Length 7.25m 7.25m 7.7m 7.25m 7.25m
Track Width 2m 2m 2m 2m 2m
Overall Width 2.65m 2.65m 2.89m 2.3m 2.3m
Unladen Weight 7560kgs 7640kg 7950kg 7560kg 7640kg
HP Required 100hp 120hp 140hp 100bp 120bp
hyd 2500 (psi max) 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min
Load Cells 12v DC 12v DC 12v DC 12v DC 12v DC

Specification 24VM RD 16VM FC 20VM FC 24VM FC
Capacity 24m3 16m3 20m3 24m3
Overall Height 3.15m 2.91m 3.00m 3.15m
Overall Length 7.7m 7.25m 7.25m 7.7m
Track Width 2m 2m 2m 2m
Overall Width 2.5m 2.3m 2.3m 2.5m
Unladen Weight 7950kg 7560kg 7640kg 7950kg
HP Required 140hp 100hp 120hp 140hp
hyd 2500 (psi max) 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min
Load Cells 12v DC 12v DC 12v DC 12v DC

**Tandem Axles increase overall height approx 100mm**
