Redrock Slurry Tanker – Non Recessed Single Axle

  • Overview
  • Specifications
  • Gallery


The Redrock slurry tanker range is built to the highest quality. Rolled from 6mm steel, all the tanks are welded both internally and externally and include 4” x 2” channel rings welded inside the tank for extra strength and a longer service life. The Redrock body, wheel arches, supports and draw-bar are designed and manufactured to the most exacting standards to maintain rigidity, reliability and road-worthiness year after year.

High Grade Rolled Steel – All Redrock vacuum tankers are made with 6mm high grade rolled steel. The tankers are welded internally and externally and fitted with anti-enclosure rings to ensure the strains exerted on the tank are limited.

Drawbar – All vacuum tanker drawbars are made full length and attached in front of the axle/axles so the tank is pulled from the front point of the running gear reducing stress on the tank.

Standard Features – The Redrock vacuum tanker is fitted with hose hooks on both sides, three sight glasses at front and one sight glass at rear.

Jurop Vacuum Pumps – Jurop vacuum pumps are fitted as standard and the spreading and suction controls are operated hydraulically. Tanks are fitted with anti-implosion valves and pressure relief valves for safety.

Commerical Axles – Commercial axles are fitted to all tanks 1600 Gallon (7200ltrs) and above and these are fitted with 28.1 x 26 wheels or above, for increased braking efficiency.

Wheel Options – A wide range of wheel options are available to choose from, and there are also many optional extra’s available to tailor your tanker to your individual needs.


Model – Slurry Tanker – Non Recessed Single Axle

Specification 1100g 1300g 1600g
Litre 5000 5900 7250
Wheel Size 550/60 R22.5 550/60 R22.5 550/60 R22.5
Overall width (mm) 2500 2500 2500
Overall Length (mm) 6050 6050 6700
Barrel Diameter (mm) 1370 1525 1525
Pump Size (Litre / min) 9000 9000 9000
