Overview
Redrock trailers are designed and built to operate in the most demanding of agricultural environments. Superior design techniques are applied to all aspects of the trailers from a strong and stable chassis to the tough, modern body. Grain and silage trailers range from 10.5 tonnes to 20 tonnes in capacity.
Features
Superior Design Techniques – Superior design techniques are applied to all aspects of the trailer from a strong and stable chassis to the tough, modern body.
High Speed Commercial Axles – Redrock Trailers are fitted with high speed commercial axles as standard with 420×180 brakes giving approx 50% braking efficiency. The option of air and hydraulic brakes is available.
150mm Taper – Redrock trailers have a 150mm taper as standard meaning the trailer will empty every time with out fail.
High Quality Pressed Steel – The body is fabricated from high quality pressed steel for strength and fully welded to prevent dirt and water build up
- Off centre Bogie axle
- Hydraulic four ram braking
- HD hitch eye
- 65mm bronze bushed bogiepin with grease track
- LED lights
- Auto silage gate latches
- Front aluminum ladder
- Commercial 10 stud axles 420 x 180 brake
- Perspex front window
- Twin tipping rams
Specifications
| Dimensions | |||
| Model | Length Width | Cubic Capacity | Axle option |
| 160/13.0 | 16’0x7’6” Tapered | 13.1m³/22.4m³ | Sprung or Bogie |
| 160/10.5 | 16’0x7’6” Tapered | 16.4m³/25.0m³ | Sprung or Bogie |
| 180/14.5 | 18’0x7’6” Tapered | 18.5m³/29.0m³ | Sprung or Bogie |
| 200/16.5 | 20’0x7’6” Tapered | 20.5m³/32.0m³ | Sprung only |
| 200/20.0 | 20’0x7’6” Tapered | 24.0m³ | Sprung only |
