McHale Fusion Vario

The McHale Fusion Vario is a fully integrated baler wrapper, which consists of a high output variable chamber baler with an integrated wrapping ring.

It can wrap the following bale types: Hay/Straw, Haylage/Silage.

HAY/ STRAW: The McHale Fusion Vario has the ability to make bales of hay and straw from 0.6 metres up to 1.68 metres or from 2′ up to 5′ 6″ .

HAYLAGE/ SILAGE: The McHale Fusion Vario can also produce bales of haylage or silage from 1.1 metres up to 1.45 metres or 3′ 3″ up to 4′ 8″ .

STANDARD SPECIFICATION

• 2.1 metre, five tine bar pick up
• Crop roller
• 15 Knife chopper system with heavy duty rotor
• Drop floor unblocking system
• Double drive variable bale chamber
• 3 belt bale chamber with endless belts
• Crop flow indicators
• Patented bale transfer delivering higher output
• High speed vertical wrapping ring
• i Touch control system
• Inbuilt camera system
• Fully automatic operation

i TOUCH CONTROL SYSTEM

• Large incab display
• Touch screen control
• Inbuilt camera technology

Dimensions & Weight

• Lenght: 6.3m
• Width: 2.94m
• Height: 3.3m
• Weight: 6500kgs

Pick-Up

• Working Width: 2100 mm
• Tine Bars: 5
• Tine Spacing: 70 mm
• Short Crop Guard: Option
• Crop Roller: Standard
• Pick Up Guide Wheels (pneumatic): Standard

Chopper Unit

• Number of Knives: 15
• Theoretical Chop Length: 65 mm
• Knife Protection: Hydraulic
• Knife Deactivation: Hydraulic from Tractor Cab
• Unblocking System: Drop Floor

Bale Chamber

• Diameter: 0.6 m to 1.68 m
• Width: 1.23 m
• Bale Chamber Feed: V660 Rotor
• Number of Belts:

Net Wrap

• Control: Manual or Automatic
• Net System: Vario Stretch
• Net Roll Capacity: 1+1 Storage
• Net Adjustment: In Cab

Transmission

• Gearbox: Split Drive
• Main Drive Protection: Cam Clutch
• Pick Up Protection: Slip Clutch
• Chain Lubrication: Continuous
• Bale Chamber: Double Drive

Control

• Control System: i Touch System
• Operation: Fully Automatic
• Density Adjustment: In Cab
• Bale Size Adjustment: In Cab
• Inbuilt Camera: Standard

Other

• Axle: 8 stud
• Tyre Sizes: 650/ 50R 22.5
• Electronics: 12 Volt DC, 15 amp approx.
• Road Lights: Standard

Tractor

• Minimum Hydraulic Flow: 45 litres/ min at 180 bar
• Hydraulic System: Open, Closed or Load Sensing
• Minimum PTO Power Requirements: 85kW (114hp)
