Overview
Major Cyclone Rotary Mower
Three Point Linkage
The MAJOR Range of Cyclone Mowers has been designed to do the work of a flail mower but requires a fraction of the power and fuel that a flail mower would consume.
These machines are strong, rugged and robust; specifically designed for use in set-aside, forestry margin management and sensitive environmental scrubland control. This machine easily copes with the toughest of conditions including shrub, saplings, gorse and brush as well as the clearance of arable stubble, including maize and rapeseed crops.
Strenx™ 700 MC high-strength steel is used in the manufacture of these machines. This material is stronger than steel traditionally used in machinery manufacturing. The undersole discs are produced from Hardox® 450, a wear and abrasion resistant steel.
- Can be front or rear mounted (to be specified when ordering)
- Patented ‘blender’ double chop blade system
- 25% less power and fuel consumption required than a similar sized flail machine
- Impact shock reducing swinging hardened spring steel blades
- Low maintenance machine with less wearing parts than a flail mower
- Heavy duty rear roller
“Our Cyclone has been great purchase because I can use it for mulching shrub as well as topping and general grassland maintenance and we can use a much smaller tractor now.”
Owenie Mc Gowan, Drystock Farmer, Co. Leitrim
Specifications
Major Cyclone Mower – Specifications
Model | MJ30-200 | MJ30-250 | MJ30-280 | MJ30-300 | MJ30-350 | MJ30-420 | MJ30-560 |
Overall width | 2.1m (7’) | 2.65m (8’9”) | 3.00m (10’) | 3.0m (10’) | 3.65m (12′) | 4.43m (14’6”) | 5.81m (19’) |
Cutting width | 2m (6′ 5″) | 2.5m (8’1”) | 2.80m (9’2”) | 2.85m (9′ 4″) | 3.5m (11′ 5″) | 4.20m (13’9”) | 5.60m (18’4”) |
Transport Width | 2.10m (7’) | 2.65m (8’9”) | 3.00m (10’) | 3.00m (10’) | 2.50m (8’2″) | 2.50m (8’2”) | 2.03m (6’9”) |
No. of Blades | 12 | 16 | 16 | 12 | 20 | 24 | 32 |
No. of Rotors | 3 | 4 | 4 | 3 | 5 | 6 | 8 |
Power (HP) | 50 – 100 | 70 – 120 | 80 – 120 | 80 – 140 | 90 -140 | 100 – 150 | 110 – 150 |
PTO (rpm) | 540 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
Blade speed | 75m/s | 75m/s | 58m/s | 75m/s | 58m/s | 58m/s | 58m/s |
Cutting height | 40-200mm | 40-200mm | 40-200mm | 40-200mm | 50-170mm | 50-170mm | 50-170mm |
Weight | 600kg | 785kg | 945kg | 890kg | 1120kg | 1265kg | 1680kg |
