Strautmann Giga-Vitesse CFS

  • Overview

Overview

  • Loading capacity according to DIN of 30 – 42 m
  • CFS accelerator drum
  • Double benefit
  • Spiral rotor with tine plates
  • 45-knife cutting unit
  • Power required from 93kW / 126HP

The product segment of the high-performance silage wagons is facing increasing demands with regard to higher efficiency, also in competition with forage harvesting. On the other hand, low drag resistance and low power requirement are called for when using professional forage wagons. The Strautmann Giga Vitesse CFSwith its new conveying unit (Continuous Flowing System) is now providing an almost unrivaled product for contractors and large businesses. This forage wagon is setting standards with regard to optimum charging, low power requirement and cost effectiveness.

The Giga-Vitesse CFS is continuing the successful path which Strautmann has pursued since the introduction of the Giga-Vitesse. A high-performance conveying assembly with a unique cutting unit together with a solid body and a variety of chassis types for most different conditions have gained an excellent reputation over the years.

  • Isobus – Control
  • Hydraulic – Folding Drawbar
  • CFS – Notice the advantages
  • Boogie tandem assembly – for steady roadability
TECHNICAL DATA GV CFS 3601
LENGTH 9.42m
WIDTH / OUTER WHEEL WIDTH 2.55/2.81m
HEIGHT 4.00m
LOADING VOL. (Medium Compressed) 64.6m3
WITH DOSING UNIT 60.8m3
WEIGHT (Basic Spec) 9.000kg
WITH DOSING UNIT 9.400kg
PERM. MAX. WEIGHT
– WITH LOW DRAWBAR (up to 40km/h) 22.000kg
POWER REQUIREMENT 107kW / 145HP
DIMENSIONS WITH TYRES 710/50R26.5
