Overview
TROJAN MT 35, MT 42 & MT 52
Features:
- Hugh load capacity
- 2m wide Pick Up Reel
- Quality Irish Build & Design
- Tested in Tough Terrain
- Heavy Duty rotor
- Air Brakes Available
Heavy duty gearboxes, 2m pick-up reel with 5 rows of quality tines, balanced suspension, tandem axles and wheels that work well in the field and on road.
Specifications
|
Capacity
(med. pressure)
|
35m3 |
42m3 |
52m3 |
| DIN Capacity | 20m3 | 25m3 | 30m3 |
| Power req.HP / Kw | 90 / 64 | 110 / 82 | 130 / 97 |
| Axle | Tandem | Tandem | Tandem |
| Steering | X | X | Rear axle |
| Control type | Electro-hydraulic | Electro-hydraulic | Electro-hydraulic |
| Chop length | 40mm | 40mm | 40mm |
| No. of knives | 35 | 35 | 35 |
| Rotor fingers | 7 | 7 | 7 |
| Rotor drive | Chain drive | Chain drive | Chain Drive |
| Floor conveyor | 4 chain | 4 chain | 4 chain |
| Pick – up width | 2.00 m | 2.00 m | 2.00 m |
| Wheel size options | 560/50 R22.5 | 600/50 R22.5 | 600/50 R22.5 |
| Drawbar | Hydraulic | Hydraulic | Hydraulic |
| Brakes | Hydraulic / Air | Hydraulic / Air | Hydraulic / Air |
