K-two Bio Muckspreaders

The Bio Mk 3 range of twin horizontal beater rear discharge muck spreaders are designed with the most accurate of applications in mind.

Capable of spreading a wide range of materials, these spreaders are perfect choice when spreading higher value manures such as chicken litter at lower rates and wider working widths.

Available in capacities of 14 – 36 tonnes (21.5 – 37.7m³) and with a range of optional extras, these machine also features an enhanced standard specification.

Standard product features include

• All Bios come with hardened beater teeth
• Monocoque flared body design provides increased volumetric capacity, maintaining a legal transport width, manufactured from 4 mm and 5 mm steel to cope with the most demanding applications
• Twin open flighted, dynamically balanced, horizontal rotors enclosed behind a hydraulic opening, sprung loaded and rubber lined canopy
• Two large 1,100 mm diameter spreading discs
• Market leading running gear with 150 mm square beam axle, featuring 420 x 180 mm S-cam brakes with 35 mm diameter hydraulic brake cylinders
• Twin LED light units with automatic covers
• Fitted with slurry door, wide angle front PTO shaft, slip clutch driveline protection and in-cab electric bed speed control.

Capacity

• 12 – 36 tonnes
• Flared body design aids loading and carrying capacity
• 1,600 mm internal body width

High Specification

• Hydraulic slurry door
• Torque limiting slip clutch
• Wide angle front PTO shaft
• Gearbox driven rotors

Quality Build

• Monocoque flared body enables large diameter tyres to be fitted without increasing transport width
• 75 mm diameter floor drive shafts with 6 tooth hardened sprockets
• 4 x 16 mm marine floor chains with closely spaced slats

Rotors

• Twin horizontal beaters with hardened beater teeth
• Large diameter spreader discs give a spread pattern up to 30 m wide
• Hydraulic opening rear canopy for easy and safe service access
• Sprung loaded adjustable bottom section of canopy door

Axles

• 150 mm square commercial axles
• 420 x 180 mm S-Cam brakes
• 35 mm brake cylinders
• Large wheels provide good flotation and traction in adverse conditions

Optional Extras

• Wooden extension sides
• Steel extension sides
• Sprung drawbar
• Rear hitch and ancillaries
• Manual screw jack
• Hydraulic jack
• Weigh cells c/w auto application rate control
• Tandem axle option for model 1800 and below
