Overview
Low Loaders are available from 16 tonne to 30 tonne and can be manufactured to a broad range of specifications. A standard Low Loader comes with a hardwood floor, hydraulic ramps, sprung drawbar and commercial axles.
Specifications
- Colour: Red, Green Blue or Black
- 10mm Floor, 6mm Sides
- 10 Stud commercial axle
- Spring Suspension
- Hardwood floor
- Sprung Drawbar
- Mudflaps
- Rear and Side Lights
- Rear reflectors
- Flashing beacon
- Sprung Drawbar
Optional Extras
- Cheese Wedge Ramps
- Outriggers
- Steer Axle
- Tool Box
- Steer Axle
- Air Brakes
- Abs Brakes
- Flashing Beacon
- Front Rack
Specifications
| Capacity | 16 Tonne | 24 Tonne | 30 Tonne |
| Floor Lenght | 18ft | 23ft | 23ft |
| Beaver Lenght | 5ft | 5ft | 5ft |
| Outside Width | 8ft 3″ | 8ft 3″ | 8ft 3″ |
| Height to Floor | 36″ | 36″ | 36″ |
| Commercial Axles 127mm round | Twin | Tri | Tri |
| Floor – Either Side | 40mm Hardwood Floor | ||
| Floor Down Middle | 6mm Chequer Plate | ||
| Floor Beaver | 6mm Chequer Plate | ||
| Sides | 8″ X 3″ Channel | ||
| Brakes | Hydraulic | ||
| Suspension | Spring | ||
| Drawbar | Sprung | ||
| Tyres | 245/70/17.5 | ||
