Redrock Single Auger Vertical Feeder

  • Overview
  • Specifications
  • Gallery

Overview

The Redrock Vertical mixer feeder range can mix everything from large round or square bales of silage, straw and hay, to precision cut silage, maize, meal etc.

Serrated Knives

Vertical Mixer - Serrated Knives

Serrated knives are used to efficiently chop fibrous foodstuffs to the length required for effective mixing and healthy digestion. The knives are designed to sharpen as they wear. Assisted by two counter knives which restrict material as it is driven past them.

Sweeper Arm

Vertical Mixer - Sweeper Arm

The auger incorporates a carefully positioned sweeper arm which has been painstakingly designed by Redrock to give a perfect blend of all your selected ingredients, time after time, and ensures and even, fluffy and appetising discharge that your livestock will find easy to eat.

Two Speed Drive Line Planetary System

Vertical Mixer - Two Speed Drive Line Planetary System

The two speed drive line planetary system is used to reduce horsepower requirements, lowering your fuel costs and free up larger tractors for other tasks on the farm.

Specifications

Model – Vertical Mixer Feeder – Single Auger

Specification 10VM SD 12VM SD 14VM SD 12VM RD 12VM RD
Capacity 10m3 12m3 14m3 10m3 12m3
Overall Height 2.65m 2.75m 2.95m 2.65m 2.75m
Overall Length 5.2m 5.2m 5.2m 5.2m 5.2m
Track Width 1.7m 1.7m 1.7m 1.7m 1.7m
Overall Width 2.65m 2.65m 2.65m 2.3m 2.3m
Unladen Weight 3900kgs 4000kgs 4100kgs 3900kgs 4000kgs
HP Required 70 80 90 70 80
hyd 2500 (psi max) 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min
Load Cells 12v DC 12v DC 12v DC 12v DC 12v DC

Specification 14VM RD 10VM FC 12VM FC 14VM FC
Capacity 14m3 10m3 12m3 14m3
Overall Height 2.95m 2.65m 2.75m 2.95m
Overall Length 5.2m 5.2m 5.2m 5.2m
Track Width 1.7m 1.7m 1.7m 1.7m
Overall Width 2.3m 2.3m 2.3m 2.3m
Unladen Weight 4100kgs 3900kgs 4000kgs 4100kgs
HP Required 90 70 80 90
hyd 2500 (psi max) 30ltrs/min 30ltrs/min 30ltrs/min 30ltrs/min
Load Cells 12v DC 12v DC 12v DC 12v DC

KEY: SD = Side Door Discharge | RD = Rear Door Discharge | FC = Front Door Conveyor
