Overview
The new 1160 eHoftrac – The innovation for your business!
CO2 exhaust fumes, noise and soot particles in buildings – that was yesterday! The new 1160 eHoftrac banishes emissions from your everyday work. It combines the usual useful properties and the time-tested and proven performance of our Hoftrac® with the latest technology and an environmentally conscious and cost-effective electric drive.
Original Hoftrac: The indispensable multitool
A compact and sturdy design, low centre of gravity, small turning radius, powerful performance and a variety of attachments – these features identify our Hoftrac and still determine its great success. The new 1160 eHoftrac combines the advantages of the traditional Hoftrac with the drive type of the future.
100% electric: Technology that excites
A lead-acid battery drives the eHoftrac to peak performances – and only requires an electrical connection with 400 volts to do so. Two separate electric motors are used in the machine: one for the drive and one for the drive system of the work hydraulics. This minimises the power consumption, because the performance is only drawn when it is really needed. The electric motor for the drive also allows a dynamic and powerful start-up of the machine. This can be felt in every acceleration process.
Weidemann 1160 eHoftrac Standard components
Electric motor drive
6.5 kW
Electric motor working hydraulics
9 kW
Drive system
Compact axle T80
Electric drive system, travel direction can be selected via joystick
Active standstill regulation, the vehicle is held by the engine
Hill-hold function: In the event of a standstill on a hill, the electric motor holds the machine
Tires 10.0 / 75 – 15.3 AS ET10
Steering system
Hydraulic articulated pendulum steering, 12° oscillating angle
Hydraulics
3rd Control circuit front DN10
Lock for steering valve
Driver’s Cabin
Canopy with retaining system ROPS / FOPS tested
Comfort seat with safety belt, fully suspended, weight, back and horizontal adjustment, 60 mm spring deflection
Joystick with travel direction switch
Other
Working lights (2 front, 1 rear)
Operating hour meter
Battery charge indicator
Mechanical quick-change system for attachments
Weidemann 1160 eHoftrac Dimensions
- Total length 3.983 mm
- Total length (without bucket) 3.005 mm
- Axle middle to bucket pivot pin 508 mm
- Wheelbase 1.468 mm
- Rear overhang 917 mm
- Height to top of overhead guard fixed 2.257 mm
- Height to top of overhead guard foldable (eps) 2.361 mm
- Height to top of overhead guard foldable, folded (eps) 1.948 mm
- Seat top height 1.293 mm
- Total working height 3.443 mm
- Height of bucket pivot (max.) 2.760 mm
- Load-over height 2.441 mm
- Dumping height 1.819 mm
- Operating distance for M 498 mm
- Digging depth 77 mm
- Total width 1.044 mm
- Track width 780 mm
- Ground clearance 255 mm
- Maximum radius external 2.592 mm
- Radius at the outer edge 2.138 mm
- Inside turning radius 1.017 mm
- Inclination angle 50 °
- Rollback angle at max. lifting height 50 °
- Dumping angle (max.) 40 °
- Rollback angle (on the ground) 49 °
Load capacity diagram
- a: 515 (558*) kg
- b: 672 (725*) kg
- c: 897 (963*) kg
*Values 2070 CX80 LP
Specifications
Electric motor
| Travel drive motor, rating S2 (60 minutes) | 6.5 kW |
| Hoist motor, rating S3 (15 %) | 9 kW |
Battery Standard
| Battery voltage | 48 V |
| Rated capacity K5 | 230 Ah |
| Battery weight | 450 kg |
| Charging time | 8 h |
| Running time under long-time application with heavy materials handling, uninterrupted operation | 1.5* h |
| Running time under agricultural activities, uninterrupted operation | 2 – 3.50* h |
| Running time under normal agricultural activities with interruptions (30 min. driving time, 30 min. standstill) | to 4* h |
Battery Optional
| Battery voltage | 48 V |
| Rated capacity K5 | 310 Ah |
| Battery weight (± 5 %) | 579 kg |
| Charging time | 6 h |
| Running time under long-time application with heavy materials handling, uninterrupted operation | 2.1* h |
| Running time under agricultural activities, uninterrupted operation | 2.8 – 4.50* h |
| Running time under normal agricultural activities with interruptions (30 min. driving time, 30 min. standstill) | to 5* h |
Electrical system
| Operating voltage | 12 V |
Weights
| Operating weight (standard) | 2,350 kg |
| Tipping load with bucket – machine straight | 1,348 kg |
| Tipping load with bucket – machine articulated | 1251-1307 kg |
| Tipping load with pallet fork – machine straight | 1,089 kg |
| Tipping load with pallet fork – machine articulated | 916-959 kg |
Vehicle data
| Axle | T80 |
| Cab (optional) | FSD (eps, epsPlus) |
| Ground speed | 0 – 15 km/h |
| Speed stages | 1 |
| Hydraulic oil tank capacity | 18.5 l |
Hydraulic system
| Steering hydraulics – Oil flow | 32 l/min |
| Steering hydraulics – Operating pressure | 225 bar |
Drive
| Type of drive | electrical |
| Traction drive | Universal joint shaft |
Noise values
| Average sound power level LwA | 91.8 dB(A) |
| Guaranteed sound power level LwA | 92 dB(A) |
| Specified sound pressure level LpA | 76 dB(A) |
The running times of the battery are strongly dependent on the respective application conditions, the work task and the manner of driving. This can also mean that a longer running time can also be achieved. The specified running times can also be fallen short of in extreme cases. An uninterrupted operation (e.g. 30 minutes of driving, 30 minutes of standstill) extends the running time of the battery.
Tipping load calculation according to ISO 14397
FSD = operator’s canopy eps = Easy
Protection System (fold-down operator’s canopy)
Vibrations (weighted average effective value)
Hand-arm vibrations (HAV): The hand-arm vibrations are no more than 2.5 m/s²
Whole body vibrations: This machine is equipped with a driver’s seat that meets the requirements of EN ISO 7096:2000.
When the loader is properly used, the whole body vibrations vary from below 0.5 m/s² up to a short-term maximum value.
It is recommended to use the values specified in the table when calculating the vibration values according to ISO/TR 25398:2006. At the same time the actual use conditions have to be taken into consideration.
Telescopic loaders, like wheel loaders, are to be classified by operating weight.
| Average value | Standard deviation (s) | ||||||
| Type of loader | Typical operating conditions | 1.4*aw,eqx | 1.4*aw,eqy | aw,eqz | 1.4*sx | 1.4*sy | sz |
| [m/s²] | [m/s²] | [m/s²] | [m/s²] | [m/s²] | [m/s²] | ||
| Compact wheel loader (operating weight < 4,500 kg) |
Load & carry (load and transport work) | 0.94 | 0.86 | 0.65 | 0.27 | 0.29 | 0.13 |
| Wheel loader (operating weight > 4,500 kg) |
Load & carry (load and transport work) | 0.84 | 0.81 | 0.52 | 0.23 | 0.2 | 0.14 |
| Application in extraction (harsh application conditions) | 1.27 | 0.97 | 0.81 | 0.47 | 0.31 | 0.47 | |
| Transfer drive | 0.76 | 0.91 | 0.49 | 0.33 | 0.35 | 0.17 | |
| V-operation | 0.99 | 0.84 | 0.54 | 0.29 | 0.32 | 0.14 | |
